Seamless stainless steel door trim brings true luxury under the counter
34.38" H x 29.5" W x 22.5" D
OVERVIEW
- Unique dual zone design lets you store wine and craft beer under different temperatures
- The flexible design allows built-in or freestanding use in 30" wide spaces
- Stainless steel trimmed glass doors feature modern French door swing
- Digital controls offer easy and intuitive temperature management
- Factory-installed locks offer added security to both sections
The SWBV3067B is a 30" wide wine and craft beer cooler designed for built-in installation under counters. The fully finished black cabinet also allows freestanding use. This unit includes two glass doors with a unique French door swing and seamless stainless steel trim. Both include factory installed locks and professional handles. A stainless steel kickplate completes the look. Two separate zones feature independent digital thermostats, letting you preserve red wine under warmer temperature conditions while keeping white wine or craft beer at colder temperatures. We provide six wooden wine shelves in a jet black finish and four-wire chrome shelves, letting you arrange the shelving configuration to best suit your storage needs. Recessed LED lighting lets you display all items under an attractive, energy-efficient glow.
FEATURES
Commercially approved
ETL-S listed to ANSI-NSF Standard 7 for use in commercial establishments
Built-in capable
Make the best use of space by installing this unit under the counter and flush with other cabinetry
Fully finished cabinet
Allows the unit to be used freestanding
Dual-zone design
Two independent zones allow you to store both red and white wine or craft beer at the proper conditions
Recessed LED lighting
Gentle and energy-efficient LED lighting offers an elegant view of stored items
Digital thermostats
Each zone is equipped with electronic temperature controls for easy and intuitive temperature management
Adjustable wooden and chrome shelves
Includes 6 wooden shelves for bottle storage and 4 flat wire shelves to hold craft beer cans or bottles
Professional handles
Sleek stainless steel handles add an elegant touch to any setting
Glass doors
French door swing offers a modern look, with stainless steel door trim for an added accent
Seamless stainless steel trimmed door frame
Single-piece door trim offers a more deluxe look
Factory-installed locks
Keyed locks on both zones offer separate security for interior contents
Automatic defrost
Reduced user maintenance with automatic defrost
Fan-forced cooling
Internal fans ensure both interiors have a consistent temperature from top to bottom
100% CFC free
Environmentally friendly design without ozone-damaging chemical
SPECIFICATIONS
| Overview |
| Height of Cabinet |
34.38" (87 cm) |
| Width |
29.5" (75 cm) |
| Depth |
22.5" (57 cm) |
| Depth with Handle |
24.25" (62 cm) |
| Depth with door at 90° |
36.0" (91 cm) |
| Capacity |
5.8 cu.ft. (164 L) |
| Bottles |
33 bottles |
| Defrost Type |
Automatic |
| Door |
Glass |
| Cabinet |
Black |
| US Electrical Safety |
ETL |
| Canadian Electrical Safety |
ETL-C |
| Sanitation |
ETL-S |
| Amps |
1.25 |
| Voltage/Frequency |
115 V AC/60 Hz |
| Weight |
132.0 lbs. (60 kg) |
| Shipping Weight |
137.0 lbs. (62 kg) |
| Estimated Time to Ship |
Next day shipping |
| Parts & Labor Warranty |
1 Year |
| Compressor Warranty |
5 Years |
| Wine Cellar |
| Number of Zones |
2 |
| Door Swing |
French |
| Adjustable Shelves |
Yes |
| Shelf Type |
Wire and Wood |
| Shelf Qty |
10 |
| Thermostat Type |
Digital |
| Interior Light |
Yes |
| Fan Type |
Interior and Exterior |
| Refrigerant Type |
R600a |
| Refrigerant Amount |
1.06 oz. |
| High Side PSI |
150.0 |
| Low Side PSI |
50.0 |
| Level Legs |
4 |
| Temperature Range |
41 to 64ºF |
| Interior Height 1 |
27.38" (70 cm) |
| Interior Width 1 |
11.75" (30 cm) |
| Interior Depth 1 |
17.5" (44 cm) |
| Compressor Step Width |
11.75" (30 cm) |
| Compressor Step Depth |
5.0" (13 cm) |
| Level Legs |
4 |
| Temperature Range |
41 to 64ºF |
| Interior Height 2 |
27.38" (70 cm) |
| Interior Width 2 |
11.75" (30 cm) |
| Interior Depth 2 |
17.5" (44 cm) |
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
